Part Number: ETI0001-1251AE
| |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| AC OUTPUT | |
| Output voltage: | 120 VAC true sinewave std, up to 600 VAC optional |
| Output rating: UPS |
1550
VA, 1100 watts standard 0.65-0.75 pf std, optional configurations to 24,000 VA |
| Non-linear load capacity: | Up to 100% non-linear load capability w/o derating |
| Output voltage regulation: UPS |
± 3.0%
static regulation of nominal ± 4.0% dynamic (0 to 50% load step) |
| Overload surge capacity: | 110% for 10 minutes; 125% for 30 seconds |
| Harmonic distortion: | Less than 5.0% into 100% non-linear load |
| Output frequency: UPS | 60 Hz ± 1.0% independent of input frequency; |
| Operational status |
Status,
load and battery (16) LEDs, dimmable, status/alarm contacts,
RS-232 asynchronous serial status COM port +90 dB audible alarm w/on/off |
| AC INPUT | |
| Input voltage selection: | Autoranging from nominal 115 VAC to 230 VAC |
| Input voltage tolerance: UPS | UPS +15% -25%, 80VAC to 250VAC |
| Input frequency: | From 45 Hz to 440 Hz |
| Input transient suppression: | Complies with IEEE 587 and UL 1449, Mil Std 1275B |
| Input control/protection: | Guarded 2 pole circuit breaker |
| DC INPUT / INTERNAL BATTERY | |
| External DC input: | Nominal 22 to 32 VDC |
| External DC control/protection: | Guarded 2 pole circuit breaker (CB2) |
| Internal battery type: |
Maintenance
free immobilized electrolyte, Flame retardant materials (Oxygen Index 28+) |
| Internal battery life: | Rated for continuous service life of 5 years |
| Internal battery protection: | Rear panel mounted fuse (F1) |
| Internal battery time: | 10+ minutes @ 1000 watt load, 20+ minutes @ 50% load |
| Internal battery recharge: | Recharged to nominal in <8 hours |
| Internal battery replacement: | Drawout/plug-in module from front of unit |
| DISTRIBUTION PANEL | |
| Output circuits: | Seven outputs standard, optional configurations |
| Output receptacles: | Metal shell, six with NEMA 5-15R, other options |
| MECHANICAL | |
|
Chassis Dimensions ( H x D x W ): |
6.0 x 16.0 x 16.0 in (152 x 406 x 406 mm) |
| Mounting Options: | Table, Wall, Floor, Portable, Horizontal/Vertical, Rack |
| Operating noise: | Less than 47 dB @ 5.0 ft., ANSI "A" scale |
| Cooling type: | High capacity, negative pressure, forced air |
| Cooling air direction: | Front intake, exhaust to rear |
| Air intake filter: | Washable metal filter media, others optional |
| ENVIRONMENTAL | |
| Storage temperature: | -40° to 150° F ambient (-40° to 66° C) |
| Operating temperature: | -22° to 125° F ambient ( -30° to 52° C) |
| Operating humidity: | 0 to 95% relative humidity (non-condensing) |
| Storage elevation: | Up to 40,000 ft (12,192 m), higher optionally |
| Operating elevation: | Up to 15,000 ft (4,572 m), higher optionally |
| STANDARDS | |
| United States: |
Meets
UL-1778 standard for UPS equipment, Meets MIL-STDs 1275, 167-1, 454, 810, 1399-300A & MIL-S-901 |
| Canada: | CSA C22.2 No. 107 UPS safety requirements |
| EMC (Electro Magnetic Compatibility: | EMI/RFI FCC, Class A; EN55022; MIL STD 461E |
| HEMP (High Altitude Electromagnetic Pulse): | MIL STD 2169B |
| DOCUMENTATION: | |
| Internal: | USB internal flash drive, 256 MB or larger with electronic copies O & M, Training and Troubleshooting Guides |
| OPTIONAL ACCESSORIES | |
| Emergency Power Off, Elapsed Time Meter, Cold Start, Alternate I/O Configurations, Dual Source Input, Battery Expansion, Batteryless Operation, Battery Charger/Conditioner, Power Distribution Units, Software Interface, 10BaseT Ethernet SNMP/HTTP port, Transport Cases | |
